Canadian multi-unit residential millwork: 8 decisions before fabrication

01

1. Start with the building and resident-service brief

Separate the lobby, mail and parcel area, amenity rooms, corridors, leasing or concierge points and typical suite types before choosing a cabinet layout. For each zone, record who uses it, what is stored, peak traffic, cleaning frequency and the access needed by building staff or service contractors.

The Canada Mortgage and Housing Corporation is a useful public reference for housing context, but it does not define the cabinetry scope for a particular project. The architect, operator and local code consultants must approve the project brief.

• Building, floor and suite types are coded
• Resident, delivery, staff and maintenance routes are separate
• Storage quantities follow an approved operational brief

02

2. Freeze finished dimensions and winter interfaces

Production dimensions should describe the conditions the installer will receive after flooring, wall finishes, doors, baseboards and ceiling details are complete. In Canadian projects, also mark where snow, wet boots, salt and cleaning water can reach the base, plinth, ledge and adjacent wall.

Show fillers, scribes, shadow gaps, removable skirting and adjustable components explicitly. An early shell dimension cannot confirm whether a locker door, corridor door or service panel will open after all finishes are installed.

• Finished floor, wall lining and baseboard datum
• Wet-entry, drainage and cleanable base conditions
• Access route, elevator, staging and dry-storage constraints

03

3. Coordinate parcel lockers, mail and equipment by model

List the actual parcel-locker, intercom, access-control, mailbox, display, lighting and cleaning-equipment models or approved performance requirements. A nominal niche does not define ventilation, cable bend radius, fixing, door swing, power, network access or maintenance clearance.

The client-appointed Canadian electrical, fire, accessibility and building teams confirm local requirements and connections. Joinery drawings should show only the approved openings, backing, routes and removable panels.

• Current equipment references and installation sheets
• Power, data, ventilation and service access shown
• Named owner for final connection and testing

04

4. Treat materials, hardware and cleaning as one decision

Lobby and corridor millwork is touched, wheeled past, cleaned and repaired repeatedly. Specify the substrate, finish, edge treatment, hardware family, impact-prone details, replaceable parts and cleaning method together, then review them beside the floor, wall protection and door hardware.

A sample is useful only when it is coded, dated and linked to the drawing revision. A mood image or generic durability claim is not a production instruction.

• Approved sample code, sheen and edge detail
• Hinges, runners, locks and spare-part route
• Cleaning, salt, moisture and touch-up access

05

5. Test one high-risk lobby module before repeating it

Choose a module that combines the most interfaces: a parcel locker beside a stone ledge, a concierge counter with power and data, a corridor cabinet at a door return or a storage wall with a removable service panel. Review proportion, opening, cleaning, cable access, impact protection and replacement before approving the building matrix.

Record the issue, decision, drawing revision and responsible approver. A photograph can support the record, but it does not replace the coded revision.

• Critical junction selected for review
• Issue, owner, decision and revision recorded
• Approved change propagated to every affected type

06

6. Build packaging around the Canadian installation sequence

Cartons should repeat the building, level, zone, suite type, item and drawing revision used by the installer. Separate fragile fronts, hardware kits, locker components and room-specific accessories so the receiving team can distribute a zone without opening every package.

The named local team confirms unloading, winter access, elevator reservations, dry storage, package protection and the sequence of installation. Incoterms® 2020 can allocate certain delivery costs, obligations and risks, but it does not automatically assign installation, storage, internal distribution or acceptance.

• Carton labels match drawings and packing list
• Fragile, zone-specific and spare items separated
• Unloading, storage and protection owner named

07

7. Compare proposals by release quality, not headline price

Ask each supplier to price the same building matrix and identify drawings, samples, hardware, locker coordination, packaging, labels, quality records, replacement rules and exclusions. A lower total may simply leave local coordination or winter handling outside the scope.

The useful comparison is the uncertainty left at production release. Require a clear review route and a named person who can sign the approved revision.

• Design deliverables and review rounds
• Building, zone, item, material and hardware schedule
• Quality evidence, shortage reporting and replacement route

08

8. Write the Canadian site boundary before ordering

WholeForm can develop the design, issue detailed drawings, coordinate materials and hardware, manufacture against approved information, document agreed quality checks, label and pack the millwork, and support international delivery.

The client-appointed Canadian architect, contractor, installer and licensed trades confirm final measurement, local requirements, import and delivery arrangements, unloading, winter storage, installation, connections, testing and final acceptance unless a separate written scope says otherwise. The National Building Codes of Canada portal is a starting point for the local team; it is not a substitute for project-specific code review.
